One way to assess the power of a factorial anova design is through the use of
Monte-Carlo simulation. With this approach, one generate hundreds (or thousands)
of randomly generated datasets. Analyze each one and retain the p-values from
the analyses. Then it is a simple matter to count up the proportion of p-values that are less than or
equal to your nominal alpha level.

The user written program factorialsim (search factorialsim) will perform Monte-Carlo
power analyses for two-way factorial anova designs. To use factorialsim you need to create
a data file named simdat.dta. This data file will contain one row for each cell in
your design. Here is an example:

list, sep(0)

     +----------------------+
     | a   b    n    m    s |
     |----------------------|
  1. | 1   1    8   20    9 |
  2. | 1   2    8   27    9 |
  3. | 1   3    8   19    9 |
  4. | 2   1   12   20   10 |
  5. | 2   2   12   25   10 |
  6. | 2   3   12   30   10 |
     +----------------------+

Variable a is the level of the first factor variable; variable b is the level
of the second factor variable; n is the number of observations in the cell; m
is the cell mean; and s is the cell standard deviation. The variables in the data file
must have the exact same names as shown above.

For each replication, factorialsim expands the simdat dataset on variable n.
Then, the program generates a random response variable with mean equal m and standard deviation
equal s. The program makes use of Stata’s
simulate command to collect and retain the Monte-Carlo results before
displaying the observed proportion of each of the p-values.

The examples below show how to use factorialsim for power and robustness analyses.

Example 1 – Prospective Power Analysis

Let’s say that a researcher has decided that a 2×3 factorial design meets the need of his
research project. Through a literature review and a pilot-study he has, what he thinks,
are reasonable estimates for cell means and standard deviations. Further, he figures that
it will be fairly easy to obtain 60 subjects for his studies. Of course, he will need to
find more if the power analysis reveals low power especially for the important interaction hypothesis.

The researcher has also decided to put more subjects into the experimental groups than into the
control groups. Below is the code the researcher used to create the simdat data file.

clear
input a b  n m   s
      1 1  8 20  9
      1 2  8 27  9
      1 3  8 19  9
      2 1 12 20 10
      2 2 12 25 10
      2 3 12 30 10
end
save simdat, replace

Now that the simdat data file has been created we will run the most basic factorialsim
command.

factorialsim

      command:  factorial_sim, obs(0)
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)

Simulations (100)
----+--- 1 ---+--- 2 ---+--- 3 ---+--- 4 ---+--- 5
..................................................    50
..................................................   100

alpha = .05 replications = 100

simulated power for a*b = .54
simulated power for   a = .25
simulated power for   b = .48

We won’t discuss these results because too few replications (only 100) were used.
We will rerun the command setting the reps option to 1,000. We will also
use the nodots option to suppress the display of the dots for each simulated
dataset.

factorialsim, reps(1000) nodots

      command:  factorial_sim, obs(0)
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)

alpha = .05 replications = 1000

simulated power for a*b = .486
simulated power for   a = .229
simulated power for   b = .415

This proposed design seems to be under powered. We would like to get the power up to at
least 0.8. We can see what would happen if we were to increase each of the cell sizes to
20 observations using the obs command.

factorialsim, reps(1000) obs(20) nodots

      command:  factorial_sim, obs(20)
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)

alpha = .05 replications = 1000

simulated power for a*b = .834
simulated power for   a = .41
simulated power for   b = .75

Now the power looks good for the interaction and is much better for the b main effect.
However, the a main effect still lacks power. Since the interaction has good power the
researcher must decide whether to stick with this sample size or increase it until the
main effect for a has a simulated power of 0.8.

It is also possible to run the analysis with the robust option. The robust
option causes factorialsim to run the model using regress with Huber-White
robust standard errors. Below we will rerun the analysis with obs(20) as in the
previous example.

factorialsim, reps(1000) nodots robust obs(20)

      command:  factorial_simr, obs(20)
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)

alpha = .05 replications = 1000

simulated power for a*b = .838
simulated power for   a = .056
simulated power for   b = .748

The power for a*b and b held up very well. However, the power for a
has dropped dramatically due to heteroscedasticity between the two levels of a.

Example 2 – Observed Power Analysis

Observed (post-hoc) power analysis is one that is done after the data have been collected and analyzed.

We begin by loading a dataset (hsbdemo) and running an anova.

use https://stats.idre.ucla.edu/stat/data/hsbdemo, clearanova write female##prog

                           Number of obs =     200     R-squared     =  0.2590
                           Root MSE      = 8.26386     Adj R-squared =  0.2399

                  Source |  Partial SS    df       MS           F     Prob > F
             ------------+----------------------------------------------------
                   Model |  4630.36091     5  926.072182      13.56     0.0000
                         |
                  female |  1261.85329     1  1261.85329      18.48     0.0000
                    prog |  3274.35082     2  1637.17541      23.97     0.0000
             female#prog |  325.958189     2  162.979094       2.39     0.0946
                         |
                Residual |  13248.5141   194  68.2913097
             ------------+----------------------------------------------------
                   Total |   17878.875   199   89.843593

Next, we create a dataset that contains the frequency, mean and standard deviation for each
cell using the collapse command.

collapse collapse (mean) m=write (sd) s=write (count) n=write, by(female prog)rename female a
rename prog b

list, clean nolabel noobs

    a   b          m          s    n
    0   1   49.14286   10.36478   21
    0   2   54.61702   8.656622   47
    0   3   41.82609   8.003705   23
    1   1      53.25   8.205248   24
    1   2   57.58621   7.115672   58
    1   3   50.96296   8.341193   27

save simdat, replace

Now we can run factorialsim to get the Monte-Carlo post-hoc power estimates.

factorialsim, reps(1000) nodots

      command:  factorial_sim, obs(0)
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)


alpha = .05 replications = 1000

simulated power for a*b = .49
simulated power for   a = .98
simulated power for   b = 1

The power for the a and b main effects are more than adequate while the power for the
interaction is a bit on the low side. If we play around with the obs option
we will see that it requires around 65 observation per cell to obtain a power of
.8 for the interaction this model.

factorialsim, reps(1000) obs(65) nodots

      command:  factorial_sim, obs(65)
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)


alpha = .05 replications = 1000

simulated power for a*b = .814
simulated power for   a = 1
simulated power for   b = 1

Example 3 – Robustness Analysis

To assess robustness of a model, you just set all the mean values to be equal. factorialsim
accomplishes this by setting all of the means to zero. Next you run the Monte-Carlo simulation.
If the portion of p-values is close to the nominal alpha level then the model displays good
robustness. Depending on cell sizes and variances the observed p-values can be much smaller
then alpha or much larger.

Just to show that robustness works well under optimal conditions, we will begin with an example
in which all the cells are the same size and have the same standard deviations.

clear
input a b  n  m  s
      1 1 20 20 10
      1 2 20 27 10
      1 3 20 19 10
      2 1 20 20 10
      2 2 20 25 10
      2 3 20 30 10
      end
 save simdat, replacefactorialsim, reps(1000) nodots zero

      command:  factorial_sim, obs(0) zero
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)


alpha = .05 replications = 1000


simulated robustness for a*b = .047
simulated robustness for   a = .05
simulated robustness for   b = .056

Note that all of the Monte-Carlo simulated alpha values are very close to the
nominal 0.05 alpha levels.

Next, we will run an example in which cell size and variability differ.
In this case the smaller cells in the design have the larger variability.

clear
input a b  n  m  s
      1 1 10 20 20
      1 2 10 27 20
      1 3 10 19 20
      2 1 30 20 10
      2 2 30 25 10
      2 3 30 30 10
      end
 save simdat, replace

factorialsim, reps(1000) nodots zero

      command:  factorial_sim, obs(0) zero
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)


alpha = .05 replications = 1000

simulated robustness for a*b = .214
simulated robustness for   a = .148
simulated robustness for   b = .207

The observed proportions across our 1,000 samples is much larger that the nominal 0.05
level that is assumed.

Here’s what this analysis with the robust option looks like.

factorialsim, reps(1000) nodots zero robust

      command:  factorial_simr, obs(0) zero
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)


alpha = .05 replications = 1000

simulated robustness for a*b = .088
simulated robustness for   a = .099
simulated robustness for   b = .087

The values with robust option are much better.

Now let’s run it again, this time with the smaller cells in the design having the lower
variability.

clear
input a b  n  m  s
      1 1 10 20 10
      1 2 10 27 10
      1 3 10 19 10
      2 1 30 20 20
      2 2 30 25 20
      2 3 30 30 20
      end
 save simdat, replacefactorialsim, reps(1000) nodots zero

      command:  factorial_sim, obs(0) zero
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)


alpha = .05 replications = 1000

simulated robustness for a*b = .003
simulated robustness for   a = .005
simulated robustness for   b = .002

In this case the observed proportions are all much lower than the nominal alpha level
of 0.05.

Once again, we will rerun the analysis with the robust option.

factorialsim, reps(1000) nodots zero robust

      command:  factorial_simr, obs(0) zero
          pab:  r(pab)
           pa:  r(pa)
           pb:  r(pb)


alpha = .05 replications = 1000

simulated robustness for a*b = .055
simulated robustness for   a = .064
simulated robustness for   b = .088

The p-values, once again, are much closer to the nominal 0.05 levels than without the
robust option.

Thus, factorialsim can be a useful tool in exploring robustness in two-way factorial
designs.
