Robust regression is an alternative to least squares regression
when data are contaminated with outliers or influential observations, and it can also be used
for the purpose of detecting influential observations.

This page uses the following packages. Make sure that you can load
them before trying to run the examples on this page. If you do not have
a package installed, run: install.packages("packagename"), or
if you see the version is out of date, run: update.packages().

require(foreign)require(MASS)

Version info: Code for this page was tested in R version 3.1.1 (2014-07-10)
On: 2014-09-29
With: MASS 7.3-33; foreign 0.8-61; knitr 1.6; boot 1.3-11; ggplot2 1.0.0; dplyr 0.2; nlme 3.1-117


Please note: The purpose of this page is to show how to use various
data analysis commands. It does not cover all aspects of the research process
which researchers are expected to do. In particular, it does not cover data
cleaning and checking, verification of assumptions, model diagnostics or
potential follow-up analyses.

Introduction

Let’s begin our discussion on robust regression with some terms in linear
regression.

Residual: The difference between the predicted value (based on the
regression equation) and the actual, observed value.

Outlier: In linear regression, an outlier is an observation with
large residual. In other words, it is an observation whose dependent-variable
value is unusual given its value on the predictor variables. An outlier may
indicate a sample peculiarity or may indicate a data entry error or other
problem.

Leverage: An observation with an extreme value on a predictor
variable is a point with high leverage. Leverage is a measure of how far an
independent variable deviates from its mean. High leverage points can have a
great amount of effect on the estimate of regression coefficients.

Influence: An observation is said to be influential if removing the
observation substantially changes the estimate of the regression coefficients.
Influence can be thought of as the product of leverage and outlierness.

Cook’s distance (or Cook’s D): A measure that combines the information
of leverage and residual of the observation.

Robust regression can be used in any situation in which you would use least
squares regression. When fitting a least squares regression, we might find some
outliers or high leverage data points. We have decided that these data points
are not data entry errors, neither they are from a different population than
most of our data. So we have no compelling reason to exclude them from the
analysis. Robust regression might be a good strategy since it is a compromise
between excluding these points entirely from the analysis and including all the
data points and treating all them equally in OLS regression. The idea of robust
regression is to weigh the observations differently based on how well behaved
these observations are. Roughly speaking, it is a form of weighted and
reweighted least squares regression.

The rlm command in the MASS package command implements several versions of robust
regression. In this page, we will show M-estimation with Huber and bisquare
weighting. These two are very standard. M-estimation defines a weight function
such that the estimating equation becomes (sum_{i=1}^{n}w_{i}(y_{i} – x’b)x’_{i} = 0).
But the weights depend on the residuals and the residuals on the weights. The equation is solved using Iteratively
Reweighted Least Squares (IRLS).
For example, the coefficient matrix at iteration j is
(B_{j} = [X’W_{j-1}X]^{-1}X’W_{j-1}Y)
where the subscripts indicate the matrix at a particular iteration (not rows or columns).
The process continues until it converges. In Huber weighting,
observations with small residuals get a weight of 1 and the larger the residual,
the smaller the weight. This is defined by the weight function

begin{equation}
w(e) =
left{
begin{array}{rl}
1 quad mbox{for} quad |e| leq k \ dfrac{k}{|e|} quad mbox{for} quad |e| > k \
end{array}
right.
end{equation}

With bisquare weighting, all cases with a non-zero
residual get down-weighted at least a little.

Description of the example data

For our data analysis below, we will use the crime dataset that appears in
Statistical Methods for Social Sciences, Third Edition
by Alan Agresti and Barbara Finlay (Prentice Hall, 1997). The variables are
state id (sid), state name (state), violent crimes per 100,000
people (crime), murders per 1,000,000 (murder), the percent of
the population living in metropolitan areas (pctmetro), the percent of
the population that is white (pctwhite), percent of population with a
high school education or above (pcths), percent of population living
under poverty line (poverty), and percent of population that are single
parents (single). It has 51 observations. We are going to use poverty
and single to predict crime.

cdata<-read.dta("https://stats.idre.ucla.edu/stat/data/crime.dta")summary(cdata)

##       sid          state               crime          murder
##  Min.   : 1.0   Length:51          Min.   :  82   Min.   : 1.60
##  1st Qu.:13.5   Class :character   1st Qu.: 326   1st Qu.: 3.90
##  Median :26.0   Mode  :character   Median : 515   Median : 6.80
##  Mean   :26.0                      Mean   : 613   Mean   : 8.73
##  3rd Qu.:38.5                      3rd Qu.: 773   3rd Qu.:10.35
##  Max.   :51.0                      Max.   :2922   Max.   :78.50
##     pctmetro        pctwhite        pcths         poverty
##  Min.   : 24.0   Min.   :31.8   Min.   :64.3   Min.   : 8.0
##  1st Qu.: 49.5   1st Qu.:79.3   1st Qu.:73.5   1st Qu.:10.7
##  Median : 69.8   Median :87.6   Median :76.7   Median :13.1
##  Mean   : 67.4   Mean   :84.1   Mean   :76.2   Mean   :14.3
##  3rd Qu.: 84.0   3rd Qu.:92.6   3rd Qu.:80.1   3rd Qu.:17.4
##  Max.   :100.0   Max.   :98.5   Max.   :86.6   Max.   :26.4
##      single
##  Min.   : 8.4
##  1st Qu.:10.1
##  Median :10.9
##  Mean   :11.3
##  3rd Qu.:12.1
##  Max.   :22.1

Using robust regression analysis

In most cases, we begin by running an OLS regression and doing some
diagnostics. We will begin by running an OLS regression and looking at
diagnostic plots examining residuals, fitted values, Cook’s distance, and leverage.

summary(ols<-lm(crime~poverty+single,data= cdata))

##
## Call:
## lm(formula = crime ~ poverty + single, data = cdata)
##
## Residuals:
##    Min     1Q Median     3Q    Max
## -811.1 -114.3  -22.4  121.9  689.8
##
## Coefficients:
##             Estimate Std. Error t value Pr(>|t|)
## (Intercept) -1368.19     187.21   -7.31  2.5e-09 ***
## poverty         6.79       8.99    0.76     0.45
## single        166.37      19.42    8.57  3.1e-11 ***
## ---
## Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
##
## Residual standard error: 244 on 48 degrees of freedom
## Multiple R-squared:  0.707,	Adjusted R-squared:  0.695
## F-statistic:   58 on 2 and 48 DF,  p-value: 1.58e-13

opar<-par(mfrow=c(2,2),oma=c(0,0,1.1,0))plot(ols,las=1)

par(opar)

From these plots, we can identify observations 9, 25, and 51 as possibly
problematic to our model. We can look at these observations to see which states
they represent.

cdata[c(9,25,51),1:2]

##    sid state
## 9    9    fl
## 25  25    ms
## 51  51    dc

DC, Florida and Mississippi have either high leverage or
large residuals. We can display the observations that have relatively
large values of Cook’s D. A conventional cut-off point is ({4}/{n}),
where (n) is the number of observations in the data set. We
will use this criterion to select the values to display.

d1<-cooks.distance(ols)r<-stdres(ols)a<-cbind(cdata, d1, r)a[d1>4/51, ]

##    sid state crime murder pctmetro pctwhite pcths poverty single     d1
## 1    1    ak   761    9.0     41.8     75.2  86.6     9.1   14.3 0.1255
## 9    9    fl  1206    8.9     93.0     83.5  74.4    17.8   10.6 0.1426
## 25  25    ms   434   13.5     30.7     63.3  64.3    24.7   14.7 0.6139
## 51  51    dc  2922   78.5    100.0     31.8  73.1    26.4   22.1 2.6363
##         r
## 1  -1.397
## 9   2.903
## 25 -3.563
## 51  2.616

We probably should drop DC to begin with since it is not even a state. We
include it in the analysis just to show that it has large Cook’s D and
demonstrate how it will be handled by rlm. Now we will look at
the residuals. We will
generate a new variable called absr1, which is the absolute value of the
residuals (because the sign of the residual doesn’t matter). We then print the
ten observations with the highest absolute residual values.

rabs<-abs(r)a<-cbind(cdata, d1, r, rabs)asorted<-a[order(-rabs), ]asorted[1:10, ]

##    sid state crime murder pctmetro pctwhite pcths poverty single      d1
## 25  25    ms   434   13.5     30.7     63.3  64.3    24.7   14.7 0.61387
## 9    9    fl  1206    8.9     93.0     83.5  74.4    17.8   10.6 0.14259
## 51  51    dc  2922   78.5    100.0     31.8  73.1    26.4   22.1 2.63625
## 46  46    vt   114    3.6     27.0     98.4  80.8    10.0   11.0 0.04272
## 26  26    mt   178    3.0     24.0     92.6  81.0    14.9   10.8 0.01676
## 21  21    me   126    1.6     35.7     98.5  78.8    10.7   10.6 0.02233
## 1    1    ak   761    9.0     41.8     75.2  86.6     9.1   14.3 0.12548
## 31  31    nj   627    5.3    100.0     80.8  76.7    10.9    9.6 0.02229
## 14  14    il   960   11.4     84.0     81.0  76.2    13.6   11.5 0.01266
## 20  20    md   998   12.7     92.8     68.9  78.4     9.7   12.0 0.03570
##         r  rabs
## 25 -3.563 3.563
## 9   2.903 2.903
## 51  2.616 2.616
## 46 -1.742 1.742
## 26 -1.461 1.461
## 21 -1.427 1.427
## 1  -1.397 1.397
## 31  1.354 1.354
## 14  1.338 1.338
## 20  1.287 1.287

Now let’s run our first robust regression. Robust regression is done by
iterated re-weighted least squares (IRLS). The command for running robust regression
is rlm in the MASS package. There are several weighting functions
that can be used for IRLS. We are
going to first use the Huber weights in this example. We will then look at
the final weights created by the IRLS process. This can be very
useful.

summary(rr.huber<-rlm(crime~poverty+single,data= cdata))

##
## Call: rlm(formula = crime ~ poverty + single, data = cdata)
## Residuals:
##    Min     1Q Median     3Q    Max
## -846.1 -125.8  -16.5  119.2  679.9
##
## Coefficients:
##             Value     Std. Error t value
## (Intercept) -1423.037   167.590     -8.491
## poverty         8.868     8.047      1.102
## single        168.986    17.388      9.719
##
## Residual standard error: 182 on 48 degrees of freedom

hweights<-data.frame(state= cdata$state,resid= rr.huber$resid,weight= rr.huber$w)hweights2<-hweights[order(rr.huber$w), ]hweights2[1:15, ]

##    state   resid weight
## 25    ms -846.09 0.2890
## 9     fl  679.94 0.3595
## 46    vt -410.48 0.5956
## 51    dc  376.34 0.6494
## 26    mt -356.14 0.6865
## 21    me -337.10 0.7252
## 31    nj  331.12 0.7384
## 14    il  319.10 0.7661
## 1     ak -313.16 0.7807
## 20    md  307.19 0.7958
## 19    ma  291.21 0.8395
## 18    la -266.96 0.9159
## 2     al  105.40 1.0000
## 3     ar   30.54 1.0000
## 4     az  -43.25 1.0000

We can see that roughly, as the absolute residual goes down, the weight goes up. In other words,
cases with a large residuals tend to be down-weighted. This output shows us that the
observation for Mississippi will be down-weighted the most. Florida will
also be substantially down-weighted. All observations not shown above have
a weight of 1. In OLS regression, all
cases have a weight of 1. Hence, the more cases in the robust regression
that have a weight close to one, the closer the results of the OLS and robust
regressions.

Next, let’s run the same model, but using the bisquare weighting function.
Again, we can look at the weights.

rr.bisquare<-rlm(crime~poverty+single,data=cdata,psi= psi.bisquare)summary(rr.bisquare)

##
## Call: rlm(formula = crime ~ poverty + single, data = cdata, psi = psi.bisquare)
## Residuals:
##    Min     1Q Median     3Q    Max
##   -906   -141    -15    115    668
##
## Coefficients:
##             Value     Std. Error t value
## (Intercept) -1535.334   164.506     -9.333
## poverty        11.690     7.899      1.480
## single        175.930    17.068     10.308
##
## Residual standard error: 202 on 48 degrees of freedom

biweights<-data.frame(state= cdata$state,resid= rr.bisquare$resid,weight= rr.bisquare$w)biweights2<-biweights[order(rr.bisquare$w), ]biweights2[1:15, ]

##    state  resid   weight
## 25    ms -905.6 0.007653
## 9     fl  668.4 0.252871
## 46    vt -402.8 0.671495
## 26    mt -360.9 0.731137
## 31    nj  346.0 0.751348
## 18    la -332.7 0.768938
## 21    me -328.6 0.774103
## 1     ak -325.9 0.777662
## 14    il  313.1 0.793659
## 20    md  308.8 0.799066
## 19    ma  297.6 0.812597
## 51    dc  260.6 0.854442
## 50    wy -234.2 0.881661
## 5     ca  201.4 0.911714
## 10    ga -186.6 0.924033

We can see that the weight given to Mississippi is dramatically lower using
the bisquare weighting function than the Huber weighting function and the
parameter estimates from these two different weighting methods differ. When comparing the results of a regular OLS
regression and a robust regression, if the results are very different, you will
most likely want to use the results from the robust regression. Large
differences suggest that the model parameters are being highly influenced by
outliers. Different
functions have advantages and drawbacks. Huber weights can have difficulties
with severe outliers, and bisquare weights can have difficulties converging or
may yield multiple solutions.

As you can see, the results from the two analyses are fairly different,
especially with respect to the coefficients of single and the constant
(intercept).
While normally we are not interested in the constant, if you had centered one or
both of the predictor variables, the constant would be useful. On the
other hand, you will notice that poverty is not statistically significant
in either analysis, whereas single is significant in both analyses.

Things to consider

References

See also
