Probit regression, also called a probit model, is used to model dichotomous
or binary outcome variables. In the probit model, the inverse standard normal distribution of the probability is modeled
as a linear combination of the predictors.

This page uses the following packages. Make sure that you can load
them before trying to run the examples on this page. If you do not have
a package installed, run: install.packages("packagename"), or
if you see the version is out of date, run: update.packages().

require(aod)
require(ggplot2)

Version info: Code for this page was tested in R Under development (unstable) (2012-11-16 r61126)
On: 2012-12-15
With: ggplot2 0.9.3; aod 1.3; knitr 0.9


Please Note: The purpose of this page is to show how to use various data analysis commands.
It does not cover all aspects of the research process which researchers are expected to do. In
particular, it does not cover data cleaning and checking, verification of assumptions, model
diagnostics and potential follow-up analyses.

Examples

Example 1: Suppose that we are interested in the factors that influence
whether a political candidate wins an election. The outcome (response) variable
is binary (0/1); win or lose. The predictor variables of interest are the
amount of money spent on the campaign, the amount of time spent campaigning
negatively and whether the candidate is an incumbent.

Example 2: A researcher is interested in how variables, such as GRE (Graduate Record Exam scores), GPA
(grade point average) and prestige of the undergraduate institution, effect
admission into graduate school. The response variable, admit/don’t admit, is a
binary variable.

Description of the Data

For our data analysis below, we are going to expand on Example 2 about getting
into graduate school. We have generated hypothetical data, which
can be obtained from our website in R. Note that R requires forward slashes
(/) not back slashes () when specifying a file location even if the file is
on your hard drive.

mydata <- read.csv("https://stats.idre.ucla.edu/stat/data/binary.csv")

## convert rank to a factor (categorical variable)
mydata$rank <- factor(mydata$rank)

## view first few rowshead(mydata)

##   admit gre  gpa rank
## 1     0 380 3.61    3
## 2     1 660 3.67    3
## 3     1 800 4.00    1
## 4     1 640 3.19    4
## 5     0 520 2.93    4
## 6     1 760 3.00    2

This data set has a binary response (outcome, dependent) variable called admit.
There are three predictor variables: gre, gpa and rank. We will treat the
variables gre and gpa as continuous. The variable rank takes on the
values 1 through 4. Institutions with a rank of 1 have the highest prestige,
while those with a rank of 4 have the lowest.

summary(mydata)

##      admit            gre           gpa       rank
##  Min.   :0.000   Min.   :220   Min.   :2.26   1: 61
##  1st Qu.:0.000   1st Qu.:520   1st Qu.:3.13   2:151
##  Median :0.000   Median :580   Median :3.40   3:121
##  Mean   :0.318   Mean   :588   Mean   :3.39   4: 67
##  3rd Qu.:1.000   3rd Qu.:660   3rd Qu.:3.67
##  Max.   :1.000   Max.   :800   Max.   :4.00

xtabs(~rank + admit, data = mydata)

##     admit
## rank  0  1
##    1 28 33
##    2 97 54
##    3 93 28
##    4 55 12

Analysis methods you might consider

Below is a list of some analysis methods you may have encountered.
Some of the methods listed are quite reasonable while others have either
fallen out of favor or have limitations.

Using the Probit Model

The code below estimates a probit regression model using the glm (generalized linear model) function.
Since we stored our model output in the object “myprobit”, R will not print anything to the console. We
can use the summary function to get a summary of the
model and all the estimates.

myprobit <- glm(admit ~ gre + gpa + rank, family = binomial(link = "probit"),
    data = mydata)

## model summarysummary(myprobit)

##
## Call:
## glm(formula = admit ~ gre + gpa + rank, family = binomial(link = "probit"),
##     data = mydata)
##
## Deviance Residuals:
##    Min      1Q  Median      3Q     Max
## -1.616  -0.871  -0.639   1.156   2.103
##
## Coefficients:
##             Estimate Std. Error z value Pr(>|z|)
## (Intercept) -2.38684    0.67395   -3.54  0.00040 ***
## gre          0.00138    0.00065    2.12  0.03433 *
## gpa          0.47773    0.19720    2.42  0.01541 *
## rank2       -0.41540    0.19498   -2.13  0.03313 *
## rank3       -0.81214    0.20836   -3.90  9.7e-05 ***
## rank4       -0.93590    0.24527   -3.82  0.00014 ***
## ---
## Signif. codes:  0 '***' 0.001 '**' 0.01 '*' 0.05 '.' 0.1 ' ' 1
##
## (Dispersion parameter for binomial family taken to be 1)
##
##     Null deviance: 499.98  on 399  degrees of freedom
## Residual deviance: 458.41  on 394  degrees of freedom
## AIC: 470.4
##
## Number of Fisher Scoring iterations: 4

We can use the confint function to obtain confidence intervals for the coefficient estimates.
These will be profiled confidence intervals by default, created by profiling the likelihood function. As
such, they are not necessarily symmetric.

confint(myprobit)

## Waiting for profiling to be done...

##                  2.5 %    97.5 %
## (Intercept) -3.7201051 -1.076328
## gre          0.0001104  0.002655
## gpa          0.0960655  0.862610
## rank2       -0.7992114 -0.032995
## rank3       -1.2230956 -0.405008
## rank4       -1.4234218 -0.459539

We can test for an overall effect of rank using the wald.test
function of the aod library. The
order in which the coefficients are given in the table of coefficients is the
same as the order of the terms in the model. This is important because the
wald.test function refers to the coefficients by their order in
the model.
We use the wald.test function. b
supplies the coefficients, while Sigma supplies the variance covariance
matrix of the error terms, finally Terms tells R which terms in the model
are to be tested, in this case, terms 4, 5, and 6, are the three terms for the
levels of rank.

wald.test(b = coef(myprobit), Sigma = vcov(myprobit), Terms = 4:6)

## Wald test:
## ----------
##
## Chi-squared test:
## X2 = 21.4, df = 3, P(> X2) = 8.9e-05

The chi-squared test statistic of 21.4 with three degrees of freedom is
associated with a p-value of less than 0.001 indicating that the overall effect of
rank is statistically significant.

We can also test additional hypotheses about the differences in the
coefficients for different levels of rank. Below we
test that the coefficient for rank=2 is equal to the coefficient for rank=3.
The first line of code below creates a vector l that defines the test we
want to perform. In this case, we want to test the difference (subtraction) of
the terms for rank=2 and rank=3 (i.e. the 4th and 5th terms in the
model). To contrast these two terms, we multiply one of them by 1, and the other
by -1. The other terms in the model are not involved in the test, so they are
multiplied by 0. The second line of code below uses L=l to tell R that we
wish to base the test on the vector l (rather than using the Terms option
as we did above).

l <- cbind(0, 0, 0, 1, -1, 0)
wald.test(b = coef(myprobit), Sigma = vcov(myprobit), L = l)

## Wald test:
## ----------
##
## Chi-squared test:
## X2 = 5.6, df = 1, P(> X2) = 0.018

The chi-squared test statistic of 5.5 with 1 degree of freedom is associated with
a p-value of 0.019, indicating that the difference between the coefficient for rank=2
and the coefficient for rank=3 is statistically significant.

You can also use predicted probabilities to help you understand the model.
To do this, we first create a data frame containing
the values we want for the independent variables.

newdata <- data.frame(gre = rep(seq(from = 200, to = 800, length.out = 100),
    4 * 4), gpa = rep(c(2.5, 3, 3.5, 4), each = 100 * 4), rank = factor(rep(rep(1:4,
    each = 100), 4)))

head(newdata)

##     gre gpa rank
## 1 200.0 2.5    1
## 2 206.1 2.5    1
## 3 212.1 2.5    1
## 4 218.2 2.5    1
## 5 224.2 2.5    1
## 6 230.3 2.5    1

Now we can predict the probabilities for our input data as well as their standard errors.
These are stored as new variable in the data frame with the original data, so we can
plot the predicted probabilities for different gre scores. We create four plots,
one for each level of gpa we used (2.5, 3, 3.5, 4) with the colour of the lines
indicating the rank the predicted probabilities were for.

newdata[, c("p", "se")] <- predict(myprobit, newdata, type = "response", se.fit = TRUE)[-3]

ggplot(newdata, aes(x = gre, y = p, colour = rank)) + geom_line() + facet_wrap(~gpa)

We may also wish to see measures of how well our model fits. This can be
particularly useful when comparing competing models. The output produced by
summary(mylogit) included indices of fit (shown below the coefficients), including the null and
deviance residuals and the AIC. One measure of model fit is the significance of
the overall model. This test asks whether the model with predictors fits
significantly better than a model with just an intercept (i.e. a null model).
The test statistic is the difference between the residual deviance for the model
with predictors and the null model. The test statistic is distributed
chi-squared with degrees of freedom equal to the differences in degrees of freedom between
the current and the null model (i.e. the number of predictor variables in the
model). To find the difference in deviance for the two models (i.e. the test
statistic) we can compute the change in deviance, and test it using a chi square test—the
change in deviance distributed as chi square on the change in degrees
of freedom.

## change in deviancewith(myprobit, null.deviance - deviance)

## [1] 41.56

## change in degrees of freedomwith(myprobit, df.null - df.residual)

## [1] 5

## chi square test p-valuewith(myprobit, pchisq(null.deviance - deviance, df.null - df.residual, lower.tail = FALSE))

## [1] 7.219e-08

The chi-square of 41.56 with 5 degrees of freedom and an associated p-value of less than 0.001 tells us that our model as a whole fits
significantly better than an empty model. This is sometimes called a likelihood
ratio test (the deviance residual is -2*log likelihood). To see the
model’s log likelihood, we type:

logLik(myprobit)

## 'log Lik.' -229.2 (df=6)
