Note: This example was done using Mplus version 5.2.  The syntax
may not work, or may function differently, with other versions of Mplus.

As the name implies, multivariate regression is a technique that estimates a
single regression model with more than one outcome variable. When there is more
than one predictor variable in a multivariate regression model, the model is a
multivariate multiple regression.

Please note: The purpose of this page is to show how to use various data analysis commands.
It does not cover all aspects of the research process which researchers are expected to do. In
particular, it does not cover data cleaning and checking, verification of assumptions, model
diagnostics and potential follow-up analyses.

Examples of multivariate regression analysis

Example 1. A researcher has collected data on three psychological variables,
four academic variables (standardized test scores), and the type of educational
program the student is in for 600 high school students. She is interested in how
the set of psychological variables is related to the academic variables and the
type of program the student is in.

Example 2. A doctor has collected data on cholesterol, blood pressure, and
weight.  She also collected data on the eating habits of the subjects
(e.g., how many ounces of red meat, fish, dairy products, and chocolate consumed
per week).  She wants to investigate the relationship between the three
measures of health and eating habits.

Example 3. A researcher is interested in determining what factors influence
the health African Violet plants.  She collects data on the average leaf
diameter, the mass of the root ball, and the average diameter of the blooms, as
well as how long the plant has been in its current container.  For predictor variables,
she measures several elements in the soil, as well as the amount of light
and water each plant receives.

Description of the data

Let’s pursue Example 1 from above.

We have a hypothetical dataset with 600 observations on seven variables which
can be obtained by clicking on mvreg.dat.
The psychological variables are locus of control (locus), self-concept (self), and
motivation (motiv). The academic variables are standardized tests scores in
reading (read), writing (write), and science (science), as well as a categorical
variable (prog) giving the type of program the student is in; general (prog=1), academic
(prog=2), or
vocational (prog=3). In addition to the three-category variable prog, the dataset
contains a dummy variable for each level of prog (prog1, prog2,
and prog3), for example, prog1 is equal to 1 when prog=1
(general),
and 0 otherwise. You can store the data file anywhere you like, but our examples will
assume it has been stored in c:data.  (Note that the names of
variables should NOT be included at the top of the data file.  Instead, the
variables are named as part of the variable command.) You may want to do your
descriptive statistics in a general use statistics package, such as SAS, Stata
or SPSS, because the options for obtaining descriptive statistics are limited in
Mplus. Even if you chose to run descriptive statistics in another package, it is
a good idea to run a model with type=basic before you do anything else,
just to make sure the dataset is being read correctly. The input file below
shows such a model.

Data:
  File is c:datamvreg.dat ;
Variable:
  Names are locus self motiv read write science prog prog1 prog2 prog3;
  Missing are all (-9999) ;
analysis:
  type = basic;

As we mentioned above, you will want to look at the output from this command carefully to be sure that
the dataset was read into Mplus correctly.  You will want to make sure that
you have the correct number of observations, and that the variables all have
means that are close to those from the descriptive statistics generated in a
general purpose statistical package. If there are missing values for some or all
of the variables, the descriptive statistics generated by Mplus will not match
those from a general purpose statistical package exactly, because by default, Mplus versions
5.0 and later use maximum likelihood based procedures for handling missing
values.

<output omitted>

SUMMARY OF ANALYSIS

Number of groups                                                 1
Number of observations                                         600

<output omitted>


     SAMPLE STATISTICS


           Means
              LOCUS         SELF          MOTIV         READ          WRITE
              ________      ________      ________      ________      ________
      1         0.097         0.005         0.004        51.902        52.385


           Means
              SCIENCE       PROG          PROG1         PROG2         PROG3
              ________      ________      ________      ________      ________
      1        51.763         2.088         0.230         0.452         0.318

Analysis methods you might consider

Below is a list of some analysis methods you may have encountered.
Some of the methods listed are quite reasonable while others have either
fallen out of favor or have limitations.

Multivariate regression analysis

The input file for our multivariate regression in Mplus is shown below. In the variable command, the
usevariables option is used because only some of the variables in our dataset are used in the model.
In the model command, each of the outcome variables (i.e., locus, self, and
motiv) is predicted by the four predictor variables using the keyword
on. In the output command we have requested fully standardized output
(in addition to the unstandardized coefficients) using the stdyx option, this will produce standardized estimates of the
coefficients, which you may find useful, but it also requests that Mplus produce
the R-square statistic for each of the outcome variables.

data:
  file is C:datamvreg.dat ;
variable:
  names are locus self motiv read write science prog prog1 prog2 prog3;
  missing are all (-9999) ;
  usevariables are locus self motiv read write science prog2 prog3;
model:
  locus on read write science prog2 prog3;
  self on read write science prog2 prog3;
  motiv on read write science prog2 prog3;
output:
  stdyx;

SUMMARY OF ANALYSIS

Number of groups                                                 1
Number of observations                                         600

Number of dependent variables                                    3
Number of independent variables                                  5
Number of continuous latent variables                            0

Observed dependent variables

  Continuous
   LOCUS       SELF        MOTIV

Observed independent variables
   READ        WRITE       SCIENCE     PROG2       PROG3


Estimator                                                       ML
Information matrix                                        OBSERVED
Maximum number of iterations                                  1000
Convergence criterion                                    0.500D-04
Maximum number of steepest descent iterations                   20
Maximum number of iterations for H1                           2000
Convergence criterion for H1                             0.100D-03

<output omitted>

THE MODEL ESTIMATION TERMINATED NORMALLY

TESTS OF MODEL FIT

Chi-Square Test of Model Fit

          Value                              0.000
          Degrees of Freedom                     0
          P-Value                           0.0000

Chi-Square Test of Model Fit for the Baseline Model

          Value                            311.076
          Degrees of Freedom                    18
          P-Value                           0.0000

CFI/TLI

          CFI                                1.000
          TLI                                1.000

Loglikelihood

          H0 Value                       -8807.819
          H1 Value                       -8807.819

Information Criteria

          Number of Free Parameters             24
          Akaike (AIC)                   17663.637
          Bayesian (BIC)                 17769.164
          Sample-Size Adjusted BIC       17692.970
            (n* = (n + 2) / 24)

RMSEA (Root Mean Square Error Of Approximation)

          Estimate                           0.000
          90 Percent C.I.                    0.000  0.000
          Probability RMSEA

MODEL RESULTS

                                                    Two-Tailed
                    Estimate       S.E.  Est./S.E.    P-Value

 LOCUS    ON
    READ               0.013      0.004      3.380      0.001
    WRITE              0.012      0.003      3.599      0.000
    SCIENCE            0.006      0.004      1.590      0.112
    PROG2              0.128      0.064      2.008      0.045
    PROG3              0.252      0.068      3.694      0.000

 SELF     ON
    READ               0.001      0.004      0.311      0.755
    WRITE             -0.004      0.004     -1.121      0.262
    SCIENCE            0.005      0.004      1.290      0.197
    PROG2              0.276      0.072      3.827      0.000
    PROG3              0.423      0.077      5.474      0.000

 MOTIV    ON
    READ               0.010      0.005      2.085      0.037
    WRITE              0.018      0.004      4.143      0.000
    SCIENCE           -0.009      0.005     -1.981      0.048
    PROG2              0.360      0.080      4.514      0.000
    PROG3              0.620      0.085      7.252      0.000

 SELF     WITH
    LOCUS              0.057      0.017      3.335      0.001

 MOTIV    WITH
    LOCUS              0.060      0.019      3.179      0.001
    SELF               0.130      0.022      5.935      0.000

 Intercepts
    LOCUS             -1.625      0.156    -10.401      0.000
    SELF              -0.372      0.177     -2.100      0.036
    MOTIV             -1.311      0.196     -6.689      0.000

 Residual Variances
    LOCUS              0.365      0.021     17.321      0.000
    SELF               0.470      0.027     17.320      0.000
    MOTIV              0.574      0.033     17.321      0.000

Because we used the stdyx option of the output command the
output includes standardized coefficients. We did this primarily to obtain the
R-square values for the outcome variables, so we have omitted the standardized
output to save space.

 <output omitted>

    R-SQUARE

    Observed                                        Two-Tailed
    Variable        Estimate       S.E.  Est./S.E.    P-Value

    LOCUS              0.187      0.029      6.508      0.000
    SELF               0.054      0.018      3.010      0.003
    MOTIV              0.150      0.027      5.580      0.000

If you ran a separate OLS regression
for each outcome variable, you would get exactly the same coefficients and
standard errors as shown above.  So why conduct a
multivariate regression? One advantage of estimating the series of
equations as a single model is that you can conduct tests of the coefficients
across the different outcome variables. For example, the input file below uses
the model test command to test
the null hypothesis that the coefficients for the variable read are equal to
0 in all three equations. Notice that in the model command each of the
terms we wish to test (i.e., each instance of read) is followed by a label
in parentheses (e.g., “(r1)”). These parameter labels are then used to refer to
the associated coefficients in the model test command. There are a few important
things to note about parameter labels. First, the labels must always appear at
the end of a line (but not necessarily the end of the command). Second, the
labels apply to all
parameters listed on the line (meaning all of the parameters on the line are
constrained to equality). This is why read is the only predictor variable
on the line with the label on it. In the model test command, we give the null
hypotheses we wish to test together, in this case, that each of the parameters
for read (identified as r1, r2, and r3) are simultaneously
equal to zero.

data:
  file is C:datamvreg.dat ;
variable:
  names are locus self motiv read write science prog prog1 prog2 prog3;
  missing are all (-9999) ;
  usevariables are locus self motiv read write science prog2 prog3;
model:
  locus on read (r1)
      write science prog2 prog3;
  self on read (r2)
      write science prog2 prog3;
  motiv on read (r3)
      write science prog2 prog3;
model test:
  r1 = 0;
  r2 = 0;
  r3 = 0;
output:
  stdyx;

The output generated by this syntax will be identical to the output shown above, except that
it will include the additional output generated by the model test
command, the additional
output is shown below (all other output is omitted).

Wald Test of Parameter Constraints

          Value                             14.486
          Degrees of Freedom                     3
          P-Value                           0.0023

The Wald test statistic of 14.486 with 3 degrees of freedom has an associated
p-value of 0.0023. These results reject the null hypothesis that the coefficients for
read
across the three equations are simultaneously equal to 0, in other words, the coefficients
for read, taken for all three outcomes together, are statistically significant.

We can also test the null hypothesis that the coefficients for prog=2 (prog2) and prog=3
(prog3) are simultaneously equal to 0 in the equation for locus_of_control.
When used to test the coefficients for dummy variables that form a single
categorical predictor, this type of test is sometimes called an overall
test for the effect of the categorical predictor (i.e., prog).

data:
    file is C:datamvreg.dat ;
variable:
  names are locus self motiv read write science prog prog1 prog2 prog3;
  missing are all (-9999) ;
  usevariables are locus self motiv read write science prog2 prog3;
model:
  locus on read write science
    prog2 (p1)
    prog3 (p2);
  self on read write science prog2 prog3;
  motiv on read write science prog2 prog3;
model test:
  p1 = 0;
  p2 = 0;
output:
  stdyx;

Wald Test of Parameter Constraints

          Value                             13.788
          Degrees of Freedom                     2
          P-Value                           0.0010

The results of the above test indicate that the two coefficients
together are significantly different from 0, in other words, the overall
effect of prog on locus_of_control is statistically significant.

The next example tests the null hypothesis that the coefficient for the variable
write in the equation with locus_of_control as the outcome is equal to the coefficient
for write in the equation with self_concept as the outcome. Another way
of stating this null hypothesis is that the effect of write on locus_of_control is equal to the effect of
write on self_concept.

Data:
    File is mvreg.dat ;
Variable:
  Names are locus self motiv read write science prog prog1 prog2 prog3;
  Missing are all (-9999) ;
  usevariables are locus self motiv read write science prog2 prog3;
model:
  locus on read
    write (wl)
    science prog2 prog3;
  self on read
    write (ws)
    science prog2 prog3;
  motiv on read write science prog2 prog3;
model test:
  wl = ws;

Wald Test of Parameter Constraints

          Value                             12.006
          Degrees of Freedom                     1
          P-Value                           0.0005

The results of this test indicate that the
coefficients for write with locus_of_control and
self_concept as the outcome are significantly different.

Below we test the null hypothesis that the
coefficient of science in the equation for
locus_of_control is equal to the coefficient for science in the
equation for self_concept, and that the coefficient for the variable
write in the equation with the outcome variable
locus_of_control equals the coefficient for write in the
equation with the outcome variable self_concept.

data:
  file is mvreg.dat ;
variable:
  names are locus self motiv read write science prog prog1 prog2 prog3;
  missing are all (-9999) ;
  usevariables are locus self motiv read write science prog2 prog3;
model:
  locus on read
    write (w1)
    science (s1)
    prog2 prog3;
  self on read
    write (w2)
    science (s2)
    prog2 prog3;
  motiv on read write science prog2 prog3;
model test:
  w1 = w2;
  s1 = s2;
output:
  stdyx;

Wald Test of Parameter Constraints

          Value                             12.902
          Degrees of Freedom                     2
          P-Value                           0.0016

The results of the above test indicate that taken together the
two sets of coefficients are significantly different. Note that
the degrees of freedom is now 2, reflecting the fact that we are comparing two sets
of coefficients, rather than 1.

Unlike some other packages, Mplus does not automatically provide a test for the
overall model. However, we can produce an equivalent test by constraining the
regression coefficients to 0 in our model and comparing the fit of that model to
the current saturated model. To constrain all of the regression coefficients to
0, we first constrain all of the coefficients by giving them the label n
(recall from above that the label applies to all coefficients on the line. Below
that, we use the model constraint command to fix n to 0.

Data:
  File is mvreg.dat ;
Variable:
  Names are locus self motiv read write science prog prog1 prog2 prog3;
  Missing are all (-9999) ;
  usevariables are locus self motiv read write science prog1 prog2 ;
model:
locus on read write science prog1 prog2 (n) ;
self on read write science prog1 prog2 (n);
motiv on read write science prog1 prog2 (n);
model constraint:
n = 0;

Because this isn’t the model we want to interpret, we have omitted most of the output.
Shown below are the chi-square test of model fit (which provides the overall test) and the
MODEL RESULTS section so that we can check to see we have estimated the desired model.

TESTS OF MODEL FIT

Chi-Square Test of Model Fit

          Value                            214.658
          Degrees of Freedom                    15
          P-Value                           0.0000

The chi-square test of model fit compares the fit of the current model to a saturated model. In the
models we estimated above (i.e., the unconstrained or saturated models), this value was 0, because the model was saturated (i.e., has 0 degrees of freedom). By adding
constraints to the model we have freed up 15 parameters, so now we get a
positive
value. The chi-square value of 214.658 with 15 degrees of freedom with an associated
p-value of less than 0.0001, indicates that the constrained model fits
significantly worse than the saturated model. In other words, the saturated
model shown above fits significantly better than the model with the regression
coefficients constrained to 0.

The MODEL RESULTS are shown below. It can be a good idea to check this section
to make sure the model estimated was the desired model. Note that all of the regression
coefficients (denoted ON) are constrained to 0, while the residual covariances
(denoted WITH) and variances, as well as the intercepts have been estimated.

MODEL RESULTS

                                                    Two-Tailed
                    Estimate       S.E.  Est./S.E.    P-Value

 LOCUS    ON
    READ               0.000      0.000    999.000    999.000
    WRITE              0.000      0.000    999.000    999.000
    SCIENCE            0.000      0.000    999.000    999.000
    PROG1              0.000      0.000    999.000    999.000
    PROG2              0.000      0.000    999.000    999.000

 SELF     ON
    READ               0.000      0.000    999.000    999.000
    WRITE              0.000      0.000    999.000    999.000
    SCIENCE            0.000      0.000    999.000    999.000
    PROG1              0.000      0.000    999.000    999.000
    PROG2              0.000      0.000    999.000    999.000

 MOTIV    ON
    READ               0.000      0.000    999.000    999.000
    WRITE              0.000      0.000    999.000    999.000
    SCIENCE            0.000      0.000    999.000    999.000
    PROG1              0.000      0.000    999.000    999.000
    PROG2              0.000      0.000    999.000    999.000

 SELF     WITH
    LOCUS              0.081      0.020      4.133      0.000

 MOTIV    WITH
    LOCUS              0.135      0.023      5.832      0.000
    SELF               0.167      0.025      6.791      0.000

 Intercepts
    LOCUS              0.097      0.027      3.531      0.000
    SELF               0.005      0.029      0.171      0.864
    MOTIV              0.004      0.034      0.116      0.907

 Residual Variances
    LOCUS              0.449      0.026     17.321      0.000
    SELF               0.497      0.029     17.321      0.000
    MOTIV              0.675      0.039     17.321      0.000

Things to consider

References

Afifi, A., Clark, V. and May, S. 2004. Computer-Aided Multivariate Analysis. 4th ed. Boca Raton, Fl: Chapman & Hall/CRC.
