Version info: Code for this page was tested in SAS 9.3.

Linear discriminant function analysis (i.e.,
discriminant analysis) performs a multivariate test of differences between
groups.   In addition, discriminant analysis is used to determine the
minimum number of dimensions needed to describe these differences.  A distinction is sometimes made between descriptive discriminant
analysis and predictive discriminant analysis.  We will be illustrating
predictive discriminant analysis on this page.

Please note: The purpose of this page is to show how to use various data
analysis commands.  It does not cover all aspects of the research process which
researchers are expected to do.  In particular, it does not cover data
cleaning and checking, verification of assumptions, model diagnostics or
potential follow-up analyses.

Examples of discriminant function analysis

Example 1. A large international air carrier has collected data on employees in three different job
classifications; 1) customer service personnel, 2) mechanics and 3) dispatchers.  The director of
Human Resources wants to know if these three job classifications appeal to different personality
types.  Each employee is administered a battery of psychological test which include measures
of interest in outdoor activity, sociability and conservativeness.

Example 2. There is Fisher’s (1936) classic example of discriminant analysis involving three
varieties of iris and
four predictor variables (petal width, petal length, sepal width, and sepal length).  Fisher not
only wanted to determine if the varieties differed significantly on the four continuous
variables but he was also interested in predicting variety classification for unknown individual
plants.

Description of the data

Let’s pursue Example 1 from above.

We have a data file, discrim.sas7bdat, with 244 observations on four variables.
The psychological variables are outdoor interests, social and
conservative. The categorical variable is job type with three
levels; 1) customer service, 2) mechanic, and 3) dispatcher.

Let’s look at the data.

proc means data=mylib.discrim n mean std min max;
  var outdoor social conservative;
run;

                                       The MEANS Procedure

       Variable          N            Mean         Std Dev         Minimum         Maximum
       -----------------------------------------------------------------------------------
       OUTDOOR         244      15.6393443       4.8399326               0      28.0000000
       SOCIAL          244      20.6762295       5.4792621       7.0000000      35.0000000
       CONSERVATIVE    244      10.5901639       3.7267890               0      20.0000000
       -----------------------------------------------------------------------------------

proc means data=mylib.discrim n mean std;
  class job;
  var outdoor social conservative;
run;

                                       The MEANS Procedure

                              N
                     JOB    Obs    Variable          N            Mean         Std Dev
            --------------------------------------------------------------------------
                       1     85    OUTDOOR          85      12.5176471       4.6486346
                                   SOCIAL           85      24.2235294       4.3352829
                                   CONSERVATIVE     85       9.0235294       3.1433091

                       2     93    OUTDOOR          93      18.5376344       3.5648012
                                   SOCIAL           93      21.1397849       4.5506602
                                   CONSERVATIVE     93      10.1397849       3.2423535

                       3     66    OUTDOOR          66      15.5757576       4.1102521
                                   SOCIAL           66      15.4545455       3.7669895
                                   CONSERVATIVE     66      13.2424242       3.6922397
            --------------------------------------------------------------------------



proc corr data=mylib.discrim;
  var outdoor social conservative;
run;

<**SOME OUTPUT OMITTED**>
                            Pearson Correlation Coefficients, N = 244
                                    Prob > |r| under H0: Rho=0

                                       OUTDOOR        SOCIAL      CONSERVATIVE

                    OUTDOOR            1.00000      -0.07130           0.07938
                                                      0.2672            0.2166

                    SOCIAL            -0.07130       1.00000          -0.23586
                                        0.2672                          0.0002

                    CONSERVATIVE       0.07938      -0.23586           1.00000
                                        0.2166        0.0002


proc freq data=mylib.discrim;
  tables job;
run;

                                        The FREQ Procedure

                                                     Cumulative    Cumulative
                     JOB    Frequency     Percent     Frequency      Percent
                     --------------------------------------------------------
                       1          85       34.84            85        34.84
                       2          93       38.11           178        72.95
                       3          66       27.05           244       100.00

Analysis methods you might consider

Below is a list of some analysis methods you may have
encountered.  Some of the methods listed are quite reasonable, while others
have either fallen out of favor or have limitations.

Discriminant function analysis

We will run the discriminant analysis using proc discrim with the
canonical option in the proc discrim statement to output the canonical
coefficients and canonical structure.
We could also have used proc candisc with essentially the same syntax to
obtain the same results but with slightly different output.
Please note that we will not be using all of the output that SAS
provides nor will the output be presented in the same order as it appears.
There is still a lot of output remaining so we will comment at various places
along the way.

proc candisc data=mylib.discrim out=discrim_out ;
  class job;
  var outdoor social conservative;
run;

                                      The DISCRIM Procedure
                                 Canonical Discriminant Analysis

                                           Adjusted    Approximate        Squared
                           Canonical      Canonical       Standard      Canonical
                         Correlation    Correlation          Error    Correlation

                       1    0.720661       0.716099       0.030834       0.519353
                       2    0.492659        .             0.048580       0.242713

                                                        Test of H0: The canonical correlations in
                    Eigenvalues of Inv(E)*H           the current row and all that follow are zero
                      = CanRsq/(1-CanRsq)
                                                      Likelihood Approximate
          Eigenvalue Difference Proportion Cumulative      Ratio     F Value Num DF Den DF Pr > F

        1     1.0805     0.7600     0.7712     0.7712 0.36398797       52.38      6    478 <.0001
        2     0.3205                0.2288     1.0000 0.75728681       38.46      2    240 <.0001

There are two discriminant dimensions both of which are statistically significant. The
canonical correlations for the dimensions one and two are 0.72 and 0.49 respectively.


		      Pooled Within-Class Standardized Canonical Coefficients

                         Variable                  Can1              Can2

                         OUTDOOR           -.3785725108      0.9261103825
                         SOCIAL            0.8306986150      0.2128592590
                         CONSERVATIVE      -.5171682475      -.2914406390


                                Pooled Within Canonical Structure

                         Variable                  Can1              Can2

                         OUTDOOR              -0.323098          0.937215
                         SOCIAL                0.765391          0.266030
                         CONSERVATIVE         -0.467691         -0.258743

The standardized discriminant coefficients function in a manner analogous to standardized
regression coefficients in OLS regression. For example, a one standard deviation increase
on the outdoor variable will result in a .378 standard deviation decrease in the predicted
values on discriminant function 1. The canonical structure, also known as canonical loading or
discriminant loadings, represent correlations between observed variables and the unobserved
discriminant functions (dimensions). The discriminant functions are a kind of latent variable
and the correlations are loadings analogous to factor loadings.

                                Class Means on Canonical Variables

                               JOB              Can1              Can2

                                 1       1.219100186      -0.389003864
                                 2      -0.106724637       0.714570441
                                 3      -1.419668555      -0.505904888


                        Number of Observations and Percent Classified into JOB

                  From JOB            1            2            3        Total

                         1           70           11            4           85
                                  82.35        12.94         4.71       100.00

                         2           16           62           15           93
                                  17.20        66.67        16.13       100.00

                         3            3           12           51           66
                                   4.55        18.18        77.27       100.00

                     Total           89           85           70          244
                                  36.48        34.84        28.69       100.00

                    Priors      0.33333      0.33333      0.33333

The output includes the means on the discriminant functions for each of the three groups
and a classification table. Values in the diagonal of the classification table reflect
the correct classification of individuals into groups based on their scores on the
discriminant dimensions.

Next, we will plot a graph of individuals on the discriminant dimensions.
Specifically, we are going to overlay a scatter plot of the individuals’ scores
on each dimension on top of a contour plot indicating predicted job
classification as a function of the two discriminant dimensions. To create the
contour plot, we first create a fake dataset containing a range of plausible
values.  Then we will use these fake data as a test dataset to calculate
predicted job classifications using coefficient estimates derived from the real
dataset.  The predicted job classifications are saved in the output dataset
under the variable name _into_.  We will then merge the actual job
classifications of the real data with the predicted job classifications of the
fake data into a single dataset for plotting.  Finally we will use procsgrender to plot the scatter plot and contour plot in one graph.  To
use procsgrender, we first need to define a graph template with
proctemplate, in which we provide all of our graphing
specifications.  Here, we are requesting a contour plot, where x and y are
the discriminant dimensions and the coloring indicates job classification, as
well as a scatter plot, where x and y are the two discriminant dimensions and
the job classification of each data point is indicated by a number (1,2,3).

data fakedata;
  do outdoor = 0 to 30 by 1;
    do social = 5 to 40 by 1;
      do conservative = 0 to 25 by 1;
      	output;
      end;
    end;
  end;
run;

proc discrim data=mylib.discrim testdata=fakedata testout=fake_out out=discrim_out canonical;
  class job;
  var outdoor social conservative;
run;


data plotclass;
  merge fake_out discrim_out;
run;


proc template;
  define statgraph classify;
    begingraph;
      layout overlay;
        contourplotparm x=Can1 y=Can2 z=_into_ / contourtype=fill
						 nhint = 30 gridded = false;
        scatterplot x=Can1 y=Can2 / group=job includemissinggroup=false
	                 	    markercharactergroup = job;
      endlayout;
    endgraph;
  end;
run;

proc sgrender data = plotclass template = classify;
run;

Here we see that the two discriminant dimensions do a reasonable job of
separating the job classifications: most of the actual job classifications fall
within the boundaries of the matching predicted job classification, indicated by
the coloring of the underlying contour map.  Moreover, it seems job levels
1 and 3 are rather different, while job level 2 is less separable from the other
two.
