Introduction

When a binary outcome variable is modeled using logistic regression, it is assumed that the logit transformation of the outcome variable has a linear relationship with the predictor variables.  This makes the interpretation of the
regression coefficients somewhat tricky.  In this page, we will walk through the concept of odds ratio and try to interpret the logistic regression results using the concept of odds ratio in a couple of examples.

From probability to odds to log of odds

Everything starts with the concept of probability.  Let’s say that the probability of success of some event is .8.  Then the probability of failure is 1 – .8 = .2.  The odds of success are defined as the ratio of the probability of success over the probability of failure.  In our example, the odds of success are .8/.2 = 4.  That is to say that the odds of success are  4 to 1.  If the probability of success is .5, i.e., 50-50 percent chance, then the odds of success is 1 to 1.

The transformation from probability to odds is a monotonic transformation, meaning the odds increase as the probability increases or vice versa.  Probability ranges from 0 and 1.  Odds range from 0 and positive infinity.  Below is a table of the transformation from probability to odds and we have also plotted for the range of p less than or equal to .9.

        p       odds
      .001    .001001
       .01    .010101
       .15   .1764706
        .2        .25
       .25   .3333333
        .3   .4285714
       .35   .5384616
        .4   .6666667
       .45   .8181818
        .5          1
       .55   1.222222
        .6        1.5
       .65   1.857143
        .7   2.333333
       .75          3
        .8          4
       .85   5.666667
        .9          9
      .999        999
     .9999       9999

The transformation from odds to log of odds is the log transformation (In statistics, in general, when we use log almost always it means natural logarithm).  Again this is a monotonic transformation.  That is to say, the greater the odds, the greater the log of odds and vice versa.  The table below shows the relationship among the probability, odds and log of odds.  We have also shown the plot of log odds against odds.

        p       odds     logodds
      .001    .001001  -6.906755
       .01    .010101   -4.59512
       .15   .1764706  -1.734601
        .2        .25  -1.386294
       .25   .3333333  -1.098612
        .3   .4285714  -.8472978
       .35   .5384616  -.6190392
        .4   .6666667  -.4054651
       .45   .8181818  -.2006707
        .5          1          0
       .55   1.222222   .2006707
        .6        1.5   .4054651
       .65   1.857143   .6190392
        .7   2.333333   .8472978
       .75          3   1.098612
        .8          4   1.386294
       .85   5.666667   1.734601
        .9          9   2.197225
      .999        999   6.906755
     .9999       9999    9.21024

Why do we take all the trouble doing the transformation from probability to log odds?  One reason is that it is usually
difficult to model a variable which has restricted range, such as probability.  This transformation is an attempt to get around the restricted range problem.  It maps probability ranging between 0 and 1 to log odds ranging from negative
infinity to positive infinity.  Another reason is that among all of the infinitely many choices of transformation, the log of odds is one of the easiest to understand and interpret.  This transformation is called logit transformation.  The other common choice is the probit transformation, which will not be covered here.

A logistic regression model allows us to establish a relationship between a binary outcome variable and a group of predictor
variables.  It models the logit-transformed probability as a linear relationship with the predictor variables.  More formally, let $Y$ be the binary outcome variable indicating failure/success with ${0,1}$ and $p$ be the probability of $y$ to be $1$, $p = P(Y=1)$. Let $x_1, cdots, x_k$ be a set of predictor variables.  Then the logistic regression of $Y$  on $x_1, cdots, x_k$ estimates parameter values for $beta_0, beta_1, cdots, beta_k$ via maximum likelihood method of the following equation

$$logit(p) = log(frac{p}{1-p}) = beta_0 + beta_1 x_1 + cdots + beta_k x_k.$$

Exponentiate and take the multiplicative inverse of both sides,

$$frac{1-p}{p} = frac{1}{exp(beta_0 + beta_1 x_1 + cdots + beta_k x_k)}.$$

Partial out the fraction on the left-hand side of the equation and add one to both sides,

$$frac{1}{p} = 1 + frac{1}{exp(beta_0 + beta_1 x_1 + cdots + beta_k x_k)}.$$

Change 1 to a common denominator,

$$frac{1}{p} = frac{exp(beta_0 + beta_1 x_1 + cdots + beta_k x_k)+1}{exp(beta_0 + beta_1 x_1 + cdots + beta_k x_k)}.$$

Finally, take the multiplicative inverse again to obtain the formula for the probability $P(Y=1)$,

$${p} = frac{exp(beta_0 + beta_1 x_1 + cdots + beta_k x_k)}{1+exp(beta_0 + beta_1 x_1 + cdots + beta_k x_k)}.$$

We are now ready for a few examples of logistic regressions.  We will
use a sample dataset, https://stats.idre.ucla.edu/wp-content/uploads/2016/02/sample.csv,  for the purpose of illustration.  The data
set has 200 observations and the outcome variable used will be hon, indicating if a student is in
an honors class or not.  So our p = prob(hon=1).  We will
purposely ignore all the significance tests and focus on the meaning of the
regression coefficients.  The output on this page was created using Stata with some
editing.

Logistic regression with no predictor variables

Let’s start with the simplest logistic regression, a model without any
predictor variables.  In an equation, we are modeling

logit(p)= β₀

Logistic regression                               Number of obs   =        200
                                                  LR chi2(0)      =       0.00
                                                  Prob > chi2     =          .
Log likelihood = -111.35502                       Pseudo R2       =     0.0000

------------------------------------------------------------------------------
         hon |      Coef.   Std. Err.      z    P>|z|     [95% Conf. Interval]
-------------+----------------------------------------------------------------
   intercept |   -1.12546   .1644101    -6.85   0.000    -1.447697   -.8032217
------------------------------------------------------------------------------

This means log(p/(1-p)) = -1.12546.  What is p here?  It turns out that p is
the overall probability of being in honors class ( hon = 1).  Let’s take a look at the frequency
table for hon.

        hon |      Freq.     Percent        Cum.
------------+-----------------------------------
          0 |        151       75.50       75.50
          1 |         49       24.50      100.00
------------+-----------------------------------
      Total |        200      100.00

So p = 49/200 =  .245. The odds are .245/(1-.245) = .3245 and the log of
the odds
(logit) is log(.3245) = -1.12546.  In other words, the intercept from the model with no
predictor variables is the estimated log odds of being in honors class for the whole population
of interest.  We
can also transform the log of the odds back to a probability: p = exp(-1.12546)/(1+exp(-1.12546)) =
.245, if we like.

Logistic regression with a single dichotomous predictor variables

Now let’s go one step further by adding a binary predictor variable,
female, to the model.  Writing it in an equation, the model describes the
following linear relationship.

logit(p) = β₀ + β₁*female

Logistic regression                               Number of obs   =        200
                                                  LR chi2(1)      =       3.10
                                                  Prob > chi2     =     0.0781
Log likelihood = -109.80312                       Pseudo R2       =     0.0139

------------------------------------------------------------------------------
         hon |      Coef.   Std. Err.      z    P>|z|     [95% Conf. Interval]
-------------+----------------------------------------------------------------
      female |   .5927822   .3414294     1.74   0.083    -.0764072    1.261972
   intercept |  -1.470852   .2689555    -5.47   0.000    -1.997995   -.9437087
------------------------------------------------------------------------------

Before trying to interpret the two parameters estimated above, let’s take a
look at the crosstab of the variable hon with female.

           |        female
       hon |      male     female |     Total
-----------+----------------------+----------
         0 |        74         77 |       151
         1 |        17         32 |        49
-----------+----------------------+----------
     Total |        91        109 |       200

In our dataset, what are the odds of a male being in the honors class and what are the odds
of a female being in the honors class?  We can manually calculate these odds from the
table: for males, the odds of being in the honors class are (17/91)/(74/91) =
17/74 = .23; and for females, the odds of being in the honors class are (32/109)/(77/109)
= 32/77 =
.42.  The ratio of the odds for female to the odds for male
is (32/77)/(17/74) = (32*74)/(77*17) = 1.809.  So the odds for males are 17 to 74, the
odds for females are 32 to 77, and the odds for female are about 81% higher than
the odds for males.

Now we can relate the odds for males and females and the output from the logistic
regression.  The intercept of -1.471 is the log odds for males since male is the
reference group (the variable female = 0).  Using the odds we calculated above for
males, we can confirm this: log(.23) = -1.47.  The coefficient for female is the log of odds
ratio between the female group and male group: log(1.809) = .593.  So we can get
the odds ratio by exponentiating the coefficient for female. Most
statistical packages display both the raw regression coefficients and the exponentiated coefficients for logistic regression models.  The table below is
created by Stata.

Logistic regression                               Number of obs   =        200
                                                  LR chi2(1)      =       3.10
                                                  Prob > chi2     =     0.0781
Log likelihood = -109.80312                       Pseudo R2       =     0.0139

------------------------------------------------------------------------------
         hon | Odds Ratio   Std. Err.      z    P>|z|     [95% Conf. Interval]
-------------+----------------------------------------------------------------
      female |   1.809015   .6176508     1.74   0.083     .9264389    3.532379
------------------------------------------------------------------------------

Logistic regression with a single continuous predictor variable

Another simple example is a model with a single continuous predictor variable
such as the model below.  It describes the relationship between students’
math
scores and the log odds of being in an honors class.

logit(p) = β₀ + β₁*math

Logistic regression                               Number of obs   =        200
                                                  LR chi2(1)      =      55.64
                                                  Prob > chi2     =     0.0000
Log likelihood = -83.536619                       Pseudo R2       =     0.2498

------------------------------------------------------------------------------
         hon |      Coef.   Std. Err.      z    P>|z|     [95% Conf. Interval]
-------------+----------------------------------------------------------------
        math |   .1563404   .0256095     6.10   0.000     .1061467     .206534
   intercept |  -9.793942   1.481745    -6.61   0.000    -12.69811   -6.889775
------------------------------------------------------------------------------

In this case, the estimated coefficient for the intercept is the log odds of
a student with a math score of zero being in an honors class.  In other words,
the odds of being in an honors class when the math score is zero is
exp(-9.793942) = .00005579.  These odds are very low, but if we look at the distribution of the variable
math, we will see that no one in the sample has math score lower than 30.  In
fact, all the test scores in the data set were standardized around mean of 50
and standard deviation of 10.  So the intercept in this model corresponds to the log odds of
being in an honors class when math is at the hypothetical value of zero.

How do we interpret the coefficient for math?  The coefficient and
intercept estimates give us the following equation:

log(p/(1-p)) = logit(p) = – 9.793942  +
.1563404*math

Let’s fix math at some value. We will use 54.  Then the conditional logit of being
in an honors class when the math score is held at 54 is

log(p/(1-p))(math=54) = – 9.793942 +
.1563404 *54.

We can examine the effect of a one-unit increase in math score.  When the math score is held at 55, the conditional logit of being in an honors class
is

log(p/(1-p))(math=55) = – 9.793942 +
.1563404*55.

Taking the difference of the two equations, we
have the following:

log(p/(1-p))(math=55)  – log(p/(1-p))(math
= 54) = .1563404.

We can say now that the coefficient for math is the difference in the log
odds.  In other words, for a one-unit increase in the math score, the expected
change in log odds is .1563404.

Can we translate this change in log odds to the change in odds? Indeed, we can.  Recall that logarithm
converts multiplication and division to addition and subtraction. Its inverse,
the exponentiation converts addition and subtraction back to multiplication and
division.  If we exponentiate both sides of our last equation, we have the
following:

exp[log(p/(1-p))(math=55)  – log(p/(1-p))(math
= 54)] = exp(log(p/(1-p))(math=55)) / exp(log(p/(1-p))(math
= 54)) = odds(math=55)/odds(math=54) = exp(.1563404) =
1.1692241.

So we can say for a one-unit increase in math
score, we expect to see about 17% increase in the odds of being in an honors
class.  This 17% of increase does not depend on the value that math is held at.

Logistic regression with multiple predictor variables and no interaction
terms

In general, we can have multiple predictor variables in a logistic regression
model.

logit(p) = log(p/(1-p))= β₀
+ β₁*x1
+ … + β_k*xk

Applying such a model to our example dataset, each estimated coefficient is the expected change in the log odds of being in an honors
class for a unit increase in the corresponding predictor variable holding the other
predictor
variables constant at certain value.  Each exponentiated coefficient is the ratio of two
odds, or the change in odds in the multiplicative scale for a unit increase in
the corresponding predictor variable holding other variables at certain value.  Here is an example.

logit(p) = log(p/(1-p))= β₀
 + β₁*math
+ β₂*female + β₃*read

Logistic regression                               Number of obs   =        200
                                                  LR chi2(3)      =      66.54
                                                  Prob > chi2     =     0.0000
Log likelihood = -78.084776                       Pseudo R2       =     0.2988

------------------------------------------------------------------------------
         hon |      Coef.   Std. Err.      z    P>|z|     [95% Conf. Interval]
-------------+----------------------------------------------------------------
        math |   .1229589   .0312756     3.93   0.000     .0616599    .1842578
      female |    .979948   .4216264     2.32   0.020     .1535755     1.80632
        read |   .0590632   .0265528     2.22   0.026     .0070207    .1111058
   intercept |  -11.77025   1.710679    -6.88   0.000    -15.12311   -8.417376
------------------------------------------------------------------------------

This fitted model says that, holding math and reading at a fixed value, the odds of
getting into an honors class for females (female = 1)over the odds of getting into an honors
class for males (female = 0) is exp(.979948) = 2.66.  In terms of percent change, we can say
that the odds for females are 166% higher than the odds for males.  The
coefficient for math says that, holding female and reading at a
fixed value, we will see 13% increase in the odds of getting into an honors class
for a one-unit increase in math score since exp(.1229589) = 1.13.

Logistic regression with an interaction term of two predictor variables

In all the previous examples, we have said that the regression coefficient of
a variable corresponds to the change in log odds and its exponentiated form
corresponds to the odds ratio.  This is only true when our model does not have
any interaction terms.  When a model has interaction term(s) of two predictor
variables, it attempts to describe how the effect of a predictor variable
depends on the level/value of another predictor variable.  The
interpretation of the regression coefficients become more involved.

Let’s take a simple example.

logit(p) = log(p/(1-p))= β₀
+ β₁*female
+ β₂*math + β₃*female*math

Logistic regression                               Number of obs   =        200
                                                  LR chi2(3)      =      62.94
                                                  Prob > chi2     =     0.0000
Log likelihood = -79.883301                       Pseudo R2       =     0.2826

------------------------------------------------------------------------------
         hon |      Coef.   Std. Err.      z    P>|z|     [95% Conf. Interval]
-------------+----------------------------------------------------------------
      female |  -2.899863   3.094186    -0.94   0.349    -8.964357    3.164631
        math |   .1293781   .0358834     3.61   0.000     .0590479    .1997082
 femalexmath |   .0669951     .05346     1.25   0.210    -.0377846    .1717749
   intercept |  -8.745841    2.12913    -4.11   0.000    -12.91886   -4.572823
------------------------------------------------------------------------------

In the presence of interaction term of female by math, we can
no longer talk about the effect of female, holding all other variables at
certain value, since it does not make sense to fix math and
femalexmath at certain value and still allow female change from 0 to 1!

In this simple example where we examine the interaction of a binary
variable and a continuous variable, we can think that we actually have two
equations: one for males and one for females.  For males (female=0), the equation is
simply

logit(p) = log(p/(1-p))= β₀
+ β₂*math.

For females, the equation is

logit(p) = log(p/(1-p))= (β₀
+ β₁)
+ (β₂ + β₃ )*math.

Now we can map the logistic regression output to
these two equations. So we can say that the coefficient for math is the effect
of math when female = 0.  More explicitly, we can say that for male students, a
one-unit increase in math score yields a change in log odds of 0.13.  On the other
hand, for the female students, a one-unit increase in math score yields a change in
log odds of (.13 + .067) = 0.197.  In terms of odds ratios, we can say that for
male students, the odds ratio is exp(.13)  = 1.14 for a one-unit increase
in math score and the odds ratio for female students is exp(.197) = 1.22 for a
one-unit increase in math score.  The ratio of these two odds ratios (female
over male) turns out to be the exponentiated coefficient for the interaction term
of female by math: 1.22/1.14 = exp(.067) = 1.07.
