We often examine data with the aim of making predictions.  Spatial data
analysis is no exception.  Given measurements of a variable at a set of points
in a region, we might like to extrapolate to points in the region where the
variable was not measured or, possibly, to points outside the region that we
believe will behave similarly.  We can base these predictions on our measured
values alone by kriging or we can incorporate covariates and make
predictions using a regression model.  In both scenarios, we will need to first
fit a variogram model to our data.

You can fit a variogram model graphically using the variog command
to calculate and then plot the points and assess the points with possible models
in mind; or you can fit several variogram
models using lme and compare the model fits. This page walks
through the second approach.  For an example of the other approach, see R FAQ: How do I generate a variogram for spatial data in R?.

There are several shapes that a variogram might follow and, in fitting a
variogram model, we aim to mathematically describe the shape. Some commonly used
variogram models are the spherical, exponential and Gaussian models.  In all
three of these models, the variogram increases with distance at small distances
and then levels off.  This general shape is suggestive of a spatial correlation
that is positive and strong at small distances and becomes less so as distances
increase until reaching a certain distance d.  Pairs of points separated
by a distance greater than d appear uncorrelated.

The lme linear mixed-effects regression command in the nlme R
package supports these three as covariance structures.  We will be using the thick dataset provided in the
SAS documentation
for proc variogram, which includes the measured thickness of coal seams
at different coordinates (we have converted this to a .csv file for easy use in
R). The code below installs and loads the nlme package and reads in the
data we will use.

install.packages("nlme")
library(nlme)
spdata <- read.table("https://stats.idre.ucla.edu/stat/r/faq/thick.csv", header = T, sep = ",")

We will be looking at the fit statistics of models with our three different
covariance structures and comparing the likelihoods of these models. For a baseline
likelihood, we can run a model without specifying a covariance structure and
obtain the likelihood of a “null” model that we hope to improve with information
about the spatial structure of the data.
The lme command requires a grouping variable.  Since we do not have
a grouping variable in our data, we can create a dummy variable that has
the same value for all 75 observations.

dummy <- rep(1, 75)
spdata <- cbind(spdata, dummy)

null.model <- lme(fixed = thick ~ 1, data = spdata, random = ~ 1 | dummy)
summary(null.model)

Linear mixed-effects model fit by REML
 Data: spdata
 AIC BIC logLik
 347.7511 354.6633 -170.8756

Random effects:
 Formula: ~1 | dummy
 (Intercept) Residual
StdDev: 0.7284064 2.365569

Fixed effects: thick ~ 1
 Value Std.Error DF t-value p-value
(Intercept) 40.13867 0.7779383 74 51.59621 0

Standardized Within-Group Residuals:
 Min Q1 Med Q3 Max
-2.55273316 -0.54475968 -0.01634561 0.68116097 1.92821818

Number of Observations: 75
Number of Groups: 1

Next, we can run the same model with spatial correlation structures. We can
specify such a structure with the correlation option of lme. The
structures are generated using corExp for exponential, corGaus for
Gaussian, or corSpher for spherical.  These are the three we will
show on this page, though there are two more spatial options for lme:
corLin for linear and corRatio for rational quadratics.

If we wish to see the correlation matrix we will be specifying, we can
first use the corExp command
to indicate how many and which variables are to be used in calculating
distances.  We will be using our coordinate variables east and
north. With the Initialize command, we provide our distance structure
with our dataset.  Then, based on that data and structure, a correlation
matrix based on the distances is calculated.  For a dataset with n
observations, this will yield an (we have printed just a portion below).

cs1Exp <- corExp(1, form = ~ east + north)
cs1Exp <- Initialize(cs1Exp, spdata)
corMatrix(cs1Exp)[1:10, 1:4]

              [,1]         [,2]         [,3]         [,4]
 [1,] 1.000000e+00 8.899995e-11 1.116596e-07 3.560630e-04
 [2,] 8.899995e-11 1.000000e+00 3.247567e-04 9.157127e-14
 [3,] 1.116596e-07 3.247567e-04 1.000000e+00 2.066026e-10
 [4,] 3.560630e-04 9.157127e-14 2.066026e-10 1.000000e+00
 [5,] 1.087634e-04 1.063903e-07 3.067433e-04 5.905301e-07
 [6,] 2.334579e-11 3.296153e-21 7.576799e-18 3.591706e-08
 [7,] 3.038054e-12 4.342979e-22 1.011711e-18 4.741565e-09
 [8,] 5.823563e-07 1.664325e-16 4.223333e-13 1.526776e-03
 [9,] 8.442416e-10 2.043360e-19 5.295179e-16 1.950855e-06
[10,] 6.292598e-27 1.033177e-36 2.692782e-33 1.074585e-23

When we update our null model to include an Exponential spatial correlation
structure, this will be the matrix used.  To make this update, we can use
the update command and use the correlation option in lme to input
the form of the correlation.  As we had done outside of the model, we will
do this with corExp.

exp.sp <- update(null.model, correlation = corExp(1, form = ~ east + north), method = "ML")
summary(exp.sp)
Linear mixed-effects model fit by maximum likelihood
 Data: spdata
       AIC      BIC    logLik
  167.1209 176.3909 -79.56047

Random effects:
 Formula: ~1 | dummy
         (Intercept) Residual
StdDev: 0.0003758452 2.959959

Correlation Structure: Exponential spatial correlation
 Formula: ~east + north | dummy
 Parameter estimate(s):
   range
205.4266
Fixed effects: thick ~ 1
               Value Std.Error DF  t-value p-value
(Intercept) 42.39964  2.496176 74 16.98584       0

Standardized Within-Group Residuals:
       Min         Q1        Med         Q3        Max
-2.8039702 -1.1992182 -0.7769150 -0.2194749  0.7771606

Number of Observations: 75
Number of Groups: 1

We can look at some of the model fit statistics to see if our model with
spatial correlation fits better than one without.  We do not have any
predictor variables in the model, so we are essentially just looking at whether
or not our outcome is spatially autocorrelated.  The fit statistics suggest
that there is.  We can look at two other spatial correlation structures to
see which appears to fit our data best.

gau.sp <- update(null.model, correlation = corGaus(1, form = ~ east + north), method = "ML")
summary(gau.sp)

Linear mixed-effects model fit by maximum likelihood
 Data: spdata
 AIC BIC logLik
 89.55566 98.82561 -40.77783

Random effects:
 Formula: ~1 | dummy
 (Intercept) Residual
StdDev: 7.954591e-05 2.088646

Correlation Structure: Gaussian spatial correlation
 Formula: ~east + north | dummy
 Parameter estimate(s):
 range
20.43577
Fixed effects: thick ~ 1
 Value Std.Error DF t-value p-value
(Intercept) 40.34101 0.5807745 74 69.46071 0

Standardized Within-Group Residuals:
 Min Q1 Med Q3 Max
-2.9880634 -0.7138627 -0.1153888 0.6745968 2.0869951

Number of Observations: 75
Number of Groups: 1

From the fit statistics of these models, we can see that the Gaussian
covariance structure best fits our data.  If we were to further model coal
seam thickness in this dataset and wished to indicate a spatial correlation in
the outcome, we would choose Gaussian. This is consistent with the findings of
the graphical fitting of a variogram model seen in
SAS FAQ: How do I fit a variogram model to my spatial data in SAS using Proc Variogram?.

See the
R online documentation for lme for further details on modeling options.
