R² and adjusted R² are often used to assess the fit of OLS regression
models. Below we show how to estimate the R² and adjusted R²
using the user-written command mibeta, as well as how to program these
calculations yourself in Stata. Note that mibeta uses the mi estimate
command, which was introduced in Stata 11. The
code to calculate the MI estimates of the R² and adjusted R²
can be used with earlier versions of Stata, as well as with Stata 11.
Additionally, the code to calculate R² and adjusted R² “by
hand” allows one to calculate confidence
intervals (based on Harel 2009), while mibeta does not.

Background

Without going into detail, the MI estimate of
a parameter (e.g. a regression coefficient) is the average of the estimated
coefficients from the MI datasets. The MI estimate of the standard error of a
parameter is calculated based on the standard error of the coefficient in the
individual imputations (sometimes called the within imputation variance) and the degree to which the
coefficient estimates vary across the imputations (the between imputation variance).
For more information on multiple imputation, see the “See also” section at the
bottom of the page.

R² is (among other things) the squared correlation (denoted r) between the observed and expect values of the
dependent variable, in equation form: r = sqrt(R²). As mentioned
above, the MI estimate of a parameter is typically the mean value across the
imputations, and this method can be used to estimate the R² for an MI model.
However, because of the way values of R² are distributed, directly
averaging the values may not be the most appropriate method of calculating the
central tendency (i.e. mean) of the distribution. It is possible to transform
correlation coefficients so that the mean becomes a more reasonable estimate of
central tendency. The mibeta command allows
you to use either the values of R² directly, or a transformation to calculate the MI estimate of R².
The code to estimate the R² and adjusted R² “by hand”
shows how to calculate these values using a transformation, but can be modified
to calculate the values without the transformation.

Harel (2009) suggests using Fisher’s r to z transformation when calculating
MI estimates of R² and adjusted R².
Harel’s method is to first
estimate the model and calculate the R² and/or adjusted R²
in each of the imputed datasets. Each model R²
is then transformed into a correlation (r) by taking its square-root. Fisher’s r
to z transformation is then used to transform each of the r values into a z
value. The average z across the imputations can then be calculated. Finally,
the mean of the z values is transformed back into an R². The same
procedure can be used for adjusted R² values. A few things
should be noted about this procedure. First, Harel writes that the technique works best when the number of
imputations is large. Harel also notes that as with any number of
statistical procedures, this method works best in large samples. Finally, the
results of a simulation study (presented in Harel 2009), suggest that
the resulting estimates of R² tend to be biased upwards (i.e. are too large), while estimates of adjusted R²
tend to be biased downwards (i.e. are too small). Because both estimates tend to
be biased, but in opposite directions, calculating the MI estimate for both R² and adjusted R² may be useful.

Fisher’s r to z

You may be curious about how the r to z transformation is calculated. Transforming r (i.e.
a correlation) to z is a fairly simple process. The value z is the inverse hyperbolic tangent of r, this value can also be
written as the following expression:

Stata’s atanh(…) function can be used to perform this
transformation. The variance of z can also be estimated, this variance is
later used in the calculation of a confidence interval for the MI estimate of R².
The formula for the variance of z is simple (note that it depends only on n,
i.e. sample size):

To reverse the r to z transformation, we can find the
hyperbolic tangent of z, which can also be written as:

Stata’s tanh(…) function can be used to reverse the transformation.

MI estimates of R² using mibeta

In order to use the mibeta command, you must first download the
necessary files. You can locate mibeta using the command search mibeta
.
For more information on installing user-written packages in Stata see our
FAQ: How do I use the search
command to search for programs and additional help? .

Below we open the dataset we will use for this example. You can download the dataset here: mvn_imputation or simply use the command below.  The dataset has been mi set so that it
will work with Stata’s built in mi commands (introduced in version 11), but we can use
mi set
(without any arguments) to confirm that the data has been mi set. The
output confirms that the data has been mi set and that there are 5
imputations.

use https://stats.idre.ucla.edu/wp-content/uploads/2016/02/mvn_imputation, clearmi setflong, M = 5

For our model, we will predict the variable read, using write
and math. Below we use mibeta to estimate the regression model
along with the estimates of the R² and the adjusted
R² using the MI data. Remember that you have to install the mibeta package first! As is typical for regression commands in Stata, the syntax for mibeta is simply the command
name followed by the outcome variable (read) and
the predictor variables (write and math). Note that we do not specify regress, this is assumed.

mibeta read write math

Multiple-imputation estimates                     Imputations     =          5
Linear regression                                 Number of obs   =        200
                                                  Average RVI     =     0.0827
                                                  Complete DF     =        197
DF adjustment:   Small sample                     DF:     min     =      92.88
                                                          avg     =     134.23
                                                          max     =     177.77
Model F test:       Equal FMI                     F(   2,  119.8) =      84.86
Within VCE type:          OLS                     Prob > F        =     0.0000

------------------------------------------------------------------------------
        read |      Coef.   Std. Err.      t    P>|t|     [95% Conf. Interval]
-------------+----------------------------------------------------------------
       write |   .3754693   .0738669     5.08   0.000     .2293537    .5215849
        math |   .4739484   .0723394     6.55   0.000     .3311939     .616703
       _cons |     7.3371   3.597566     2.04   0.044     .1929292    14.48127
------------------------------------------------------------------------------

Standardized coefficients and R-squared
Summary statistics over 5 imputations

             |       mean       min        p25     median        p75       max
-------------+----------------------------------------------------------------
       write |    .343877      .328   .3339322   .3446888   .3516272      .361
        math |   .4310601      .421   .4231636   .4264212   .4272021      .458
-------------+----------------------------------------------------------------
    R-square |   .4855069      .454   .4837243   .4907281   .4964925      .503
Adj R-square |   .4802836      .448   .4784829   .4855579   .4913808      .498
------------------------------------------------------------------------------

The first part of the output produced by mibeta is the imputation
information and table of estimates produced by mi estimate. This is the
same output that would have been produced if we used the
command mi estimate: regress
read write math . The second table includes information on standardized
coefficients for write and math, as well as the R² and adjusted R².
The table includes mean, minimum, maximum, and the quartiles of the distribution for each of
these values across the imputed datasets. For example, the average R² (i.e. the MI estimate) is .49, the lowest
R² from the 5 imputed datasets was .45 and the highest was .50.

As discussed above, it may make more sense to transform R² values before estimating
their mean, and then back transform in order to get interpretable values. We can use the mibeta
command to estimate the mean of the R² and adjusted R² (as well as
the standardized coefficients) using Fisher’s r to z transformation with the fisherz option as shown below.
Note that only the means will be different from the output above, because the
transformation does not change the order of the values.

mibeta read write math, fisherz

Multiple-imputation estimates                     Imputations     =          5
Linear regression                                 Number of obs   =        200
                                                  Average RVI     =     0.0827
                                                  Complete DF     =        197
DF adjustment:   Small sample                     DF:     min     =      92.88
                                                          avg     =     134.23
                                                          max     =     177.77
Model F test:       Equal FMI                     F(   2,  119.8) =      84.86
Within VCE type:          OLS                     Prob > F        =     0.0000

------------------------------------------------------------------------------
        read |      Coef.   Std. Err.      t    P>|t|     [95% Conf. Interval]
-------------+----------------------------------------------------------------
       write |   .3754693   .0738669     5.08   0.000     .2293537    .5215849
        math |   .4739484   .0723394     6.55   0.000     .3311939     .616703
       _cons |     7.3371   3.597566     2.04   0.044     .1929292    14.48127
------------------------------------------------------------------------------

Standardized coefficients and R-squared
Summary statistics over 5 imputations

             |       mean*      min        p25     median        p75       max
-------------+----------------------------------------------------------------
       write |   .3439318      .328   .3339322   .3446888   .3516272      .361
        math |   .4311597      .421   .4231636   .4264212   .4272021      .458
-------------+----------------------------------------------------------------
    R-square |    .485636      .454   .4837243   .4907281   .4964925      .503
Adj R-square |   .4804108      .448   .4784829   .4855579   .4913808      .498
------------------------------------------------------------------------------
* based on Fisher's z transformation

Calculating MI estimates of R² “by hand”

Below we show how to perform the calculations done by mibeta using
Stata syntax. As mentioned above, this method does not require access to the
suite of mi commands introduced in Stata 11. This method also has the advantage
of allowing for the calculation of confidence intervals.

We will discuss the code to calculate the MI estimate of R² in
pieces, then the entire block of syntax is given at the end of the page so that
you can easily transfer it to a .do file and run all of the code at once. Note
that because the code uses local macros, all of the code except opening the
dataset and using the mi set command must be run at the same time. For clarity the syntax
presented
step by step shows the process using only R², however, the code shown at the bottom
includes calculations for both the R² and adjusted R².

First, let’s open the dataset. The dataset has been mi set to work
with Stata’s built in mi commands (introduced in version 11), but we can use
mi set (without any arguments) to confirm that the data is formatted the way
I think it is. It is important to know how the data is formatted because in order for the syntax below to work properly, the dataset must be
stored in what Stata calls the flong style, this is essentially the same format used by
mim and produced by ice. The output from mi set confirms that
the data is formatted for Stata’s mi commands, is stored in the flong style, and
that number of imputations is equal to 5. If the dataset was mi set, but
not in the flong style, we could use the command mi convert flong to
convert it to the flong style.

use https://stats.idre.ucla.edu/stat/stata/seminars/missing_data/mvn_imputation, clear
mi set flong, M = 5

The first line of syntax below creates a local macro that contains
the name of the variable that identifies the imputation number. You can think of
a local macro as a placeholder for another piece of information, later we will
type `mid’ and Stata will interpret this to mean _mi_m . You may need to
change the variable name depending on how your dataset is formatted. If the data has been
mi set, the variable _mi_m
identifies the imputations, if the variable is formatted for mim, or was
imputed by ice, the imputation number is probably stored in the variable
_mj. The second line creates a scalar, another type of placeholder, that
contains the number of imputations, in this case, 5.
The next line uses generate to create a new variable, r2, this will be used to store the R² from each of the MI datasets. You can modify this
line by
changing the variable name or by removing it entirely (in which case the
values from individual MI datasets won’t be stored, but everything else will
work the same way). If you chose to do either, you must also modify the some of
the syntax below
to reflect these changes (this will be noted as we go along). The final two lines create
an M by 1
vector
(mz) that will be used to store the transformed values of R² so that we can make use of them.

local mid = "_mi_m"
scalar  M = 5

gen r2 = .

matrix mz = J(M,1,0)

The block of syntax below runs the regression model once in each of the
imputations, and saves the information necessary to calculate the MI estimate of the R². In the first line of syntax, the forvalues command tells Stata that the commands between the curved
brackets (i.e. { and } ) should be
repeated once for the values one to M (i.e. 1/`=M’). Because we defined M
as a scalar above (equal to 5), Stata will interpret `=M’ as being 5, so the loop will
repeat for the values 1 to 5. Note that the two symbols that surround M are
different, the first (i.e. ` ) is on the same key as the tilde (i.e. ~), and the
character following M (i.e. ‘ ) is an apostrophe, sometimes called a single
quote. Each time the commands within the loop are repeated, the local macro m
takes on a new value (by default, whole number values are used, i.e. 1,
2,…,5).

Looking at the syntax within the brackets, the first line contains the model we wish to estimate.
The quietly: prefix tells Stata to estimate the model, without displaying
the output. The command name, regress, is followed by
the name of the outcome variable, and then the list of predictor variables. The
if(…) tells Stata to estimate the model for one imputation at a
time, using the local macro mid we defined above (i.e. the name of
variable that indexes the imputations), as well as the local macro m. You can
change the model to reflect your analysis, and you can omit the quietly: prefix, but the if(…)
must remain (although you could add to it if necessary). When Stata estimates
the regression model, it temporarily stores information from the model,
including the model R² which is stored as e(r2).
The next line performs the r to z transformation on e(r2)  (i.e. atanh(sqrt(e(r2)))
), and saves the value in the appropriate row of the matrix mz. The
final
line saves the value of the R² from the model in the variable r2. If you are not creating this variable, you should
delete this command.

forvalues m = 1/`=M' {
		quietly: regress read write math if(`mid'==`m')

		matrix mz[`m',1] = atanh(sqrt(e(r2)))
		replace r2 = e(r2) in `m'
}

Now the matrix mz contains the z values (i.e. the transformed R² values) from each of the imputed datasets. We will use Stata’s
matrix language, Mata, to perform some of the calculations necessary to generate
the MI estimates of R² and its confidence interval. The first step is to
pass the scalar containing the number of imputations (i.e. M), and the matrix containing the R² values (i.e. mz) to
Mata. The st_numscalar(…), and st_matrix(…)
commands allow us to pass information from Stata to Mata, and vice versa.

mata: M = st_numscalar("M")
mata: z = st_matrix("mz")

Above we used st_numscalar(…) to pass information from Stata
to Mata, in the syntax below we use it to pass information from Mata to Stata. Below we place
the mean of z (i.e. the mean of the z values) in the scalar value Q.
Q now holds the MI estimate of z, which we will later transform back into to the MI estimate of R².

mata: st_numscalar("Q", mean(z))

To compute the variance of pooled R² we use Rubin’s formula (Rubin, 1987) which partitions total variance into “within imputation” capturing the expected uncertainty, “between imputation” capturing the estimation variability due to missing information, and an additional sampling variance. The total variance is: V_T = V_w +  V_B (1 + 1/m )

In the first line below we use Mata to estimate the between imputation variance
based on the standard formulas for MI, this value is denoted b. The
between imputation variance is used in the calculation of the
confidence intervals. The second line below uses st_numscalar to pass
b
from Mata to Stata, note that in Stata we have named the scalar B, rather than b.

mata: b = sum((z :- mean(z)):^2)/(M-1)
mata: st_numscalar("B" , b )

As mentioned above the variance of z is based only on n, this
results in a within imputation variance that is constant (1/(n-3)). The within
and between variances are combined to form V, the MI estimate of the
variance of z. The first line below uses the sample size (stored e(N)),
the between imputation variance (stored in B), and the number of
imputations (stored in M) to calculate the total variance of z. The following two lines, use the MI estimate of z (i.e.
Q), along with the estimate of V, to calculate the upper and lower
95% confidence limits for z.

scalar def V = 1/(e(N)-3) + B + B/M
scalar def uci =  Q + 1.959964*sqrt(V)
scalar def lci =  Q - 1.959964*sqrt(V)

The first line of syntax below begins with the display command, followed by some text to
display, and the expression ((tanh(r2z/`M’))^2). This expression
reverses the r to z transformation, and squares r to give the estimated R².
The second line does the same for the upper and lower confidence limits.

di "Average R-squared  = " (tanh(Q))^2
Average R-squared  = .48563602

di "95% CI   [" tanh(lci)^2 "," tanh(uci)^2 "]" _n
95% CI   [.38278305,.57971497]

If you stored the values of the R² from
each imputation as variables in the dataset, you can sort by the variable r2, and then
list
the non-missing values of r2 and r2_a. This allows you to see the
range of values for R² and adjusted R² across the imputations.

sort r2
list r2 if r2!=.

      +----------+
      |       r2 |
      |----------|
   1. | .4536123 |
   2. | .4837243 |
   3. | .4907281 |
   4. | .4964925 |
   5. | .5029773 |
      +----------+

Below is syntax to compute the MI estimate and its confidence interval in a single block. Note that unlike the above
example, this syntax estimates both the R² and the adjusted
R². As discussed above, it may be useful to calculate MI estimates for both the R²
and adjusted R² because R² tends to be biased upwards
while the adjusted R² tends to be biased downward. The estimate of the adjusted R²
for each regression model is stored
by Stata as
e(r2_a) and all subsequent values related to the adjusted R² have the
same name as for the R² with the suffix _a (e.g. the variables r2
and r2_a).

use https://stats.idre.ucla.edu/stat/stata/seminars/missing_data/mvn_imputation, clear
mi set

* EDIT: Depending on the dataset format, _mi_m may need to be replaced with _mj (ice/mim)
* or some other variable name. M should be set to equal to the number of imputations.
local mid = "_mi_m"
scalar M = 5

* generate variables to save the R^2 and adjusted R^2 from each imputation in a variable
* this is optional, but if you remove this or change the variable names,
* you will also need to edit more below.
gen r2 = .
gen r2_a = .

* create vectors
matrix mz = J(M,1,0)
matrix mz_a = J(M,1,0)

forvalues m = 1/`=M' {
		* EDIT: Define your model here, the command must include the if
		quietly: reg read write math if(`mid'==`m')

 		* write resulting z values to the matrix
 		matrix mz[`m',1] = atanh(sqrt(e(r2)))
		matrix mz_a[`m',1] = atanh(sqrt(e(r2_a)))

		* save the value of R^2 and the adjusted R^2 (optional, may require editing)
		replace r2 = e(r2) in `m'
		replace r2_a = e(r2_a) in `m'
}

* Pass information to Mata
mata: M = st_numscalar("M")
mata: z = st_matrix("mz")
mata: z_a = st_matrix("mz_a")

* MI estimate of z (i.e. mean of z)
mata: st_numscalar("Q", mean(z))
mata: st_numscalar("Q_a", mean(z_a))

* Calculate the between variance
* R^2
mata: B = sum((z :- mean(z)):^2)/(M-1)
mata: st_numscalar("B" , B )
* Adjusted R^2
mata: B_a = sum((z_a :- mean(z_a)):^2)/(M-1)
mata: st_numscalar("B_a" , B_a )

* Total variance (V). Note the within variance only needs to be calculated once
* because the n should be constant (w = 1/(n-3))
scalar def V = 1/(e(N)-3) + B + B/M
scalar def V_a = 1/(e(N)-3) + B_a + B_a/M

* CIs for z scale
* CI Q +/- z*sqrt(V)
scalar def uci =  Q + 1.959964*sqrt(V)
scalar def lci =  Q - 1.959964*sqrt(V)

scalar def uci_a =  Q_a + 1.959964*sqrt(V_a)
scalar def lci_a =  Q_a - 1.959964*sqrt(V_a)

* display results
di "Average R-squared  = " (tanh(Q))^2
di "95% CI   [" tanh(lci)^2 "," tanh(uci)^2 "]" _n
di "Average Adjusted R-squared  = "  (tanh(Q_a))^2
di "95% CI   [" tanh(lci_a)^2 "," tanh(uci_a)^2 "]"

* if you have created variables with R^2 from each imputation (optional)
sort r2
list r2 r2_a if r2!=.

See also

Citations

Harel, O. (2009). The estimation of R² and adjusted R² in incomplete data sets using
multiple imputation. Journal of Applied Statistics, 36(10), 1109-1118.
